Exterior PVDF Surface
The exposed aluminium face uses a PVDF coating selected for outdoor colour stability and resistance to normal weather exposure.
4mm PVDF ACP Panel for Outdoor Advertising Boards
4mm Outdoor Advertising ACP is manufactured for Outdoor advertising boards, billboard faces and exterior promotional panels. The panel build and factory processing can be confirmed around the finished component requirements.
- Panel thickness: 4mm
- Standard size: 1220 × 2440mm (4 × 8 ft)
- Aluminium skins: 0.20–0.40mm, selected to order
- Coating: PVDF coating
- Core: Polyethylene
What Is 4mm PVDF ACP Panel for Outdoor Advertising Boards?
The 4mm PVDF ACP panel for outdoor advertising boards uses aluminium face sheets, a polyethylene core and an exterior-grade PVDF coating. The 4mm section provides a practical balance of rigidity and workable weight for billboard faces, roadside campaign boards and large-format promotional panels made to a confirmed support layout.
PVDF coating is selected for outdoor colour retention and normal weather exposure, while the flat coated face can receive a compatible graphic system after testing. Panel dimensions, aluminium skin gauge, fastening pattern and support spacing should be confirmed together so the finished advertising board uses an appropriate panel build.
Product Data
Technical Specifications
| Item | Available specification |
|---|---|
| Panel thickness | 4mm |
| Standard sheet size | 1220 × 2440mm (4 × 8 ft) |
| Available widths | 1000mm, 1250mm, 1500mm and 1570mm |
| Available length | Up to 6000mm, subject to confirmed specification and transport requirements |
| Aluminium skin thickness | 0.20–0.40mm, selected to order |
| Surface coating | PVDF coating |
| Core | Polyethylene |
| Colour / finish | Solid, metallic or approved outdoor project colour |
| Recommended use | Outdoor advertising boards, billboard faces and exterior promotional panels |
| Factory processing | Cutting, sizing, routing, grooving and drilling to approved drawings |
Key Advantages
4mm Outdoor Advertising ACP Benefits
Large-Format Flatness
The 4mm composite section provides a stable face for broad advertising graphics when coordinated with the approved support arrangement.
Manageable Panel Weight
ACP creates a large advertising surface without the handling weight of solid aluminium plate at the same overall thickness.
Graphic System Compatibility
Printed film, vinyl or other graphic layers can be specified after the chosen coating, adhesive and preparation method are tested.
Made-to-Size Supply
Factory cutting and drilling help outdoor advertising fabricators receive panels prepared for the confirmed frame and fixing positions.
Consistent Campaign Colour
Production against an approved colour or metallic sample helps repeated billboard and campaign panels maintain a coordinated appearance.
Where It Is Used
Typical Applications
Roadside Billboard Faces
Provides a flat 4mm panel surface for large advertising graphics mounted to an engineered billboard support frame.
Commercial Campaign Boards
Supports exterior promotional graphics for retail parks, dealerships, construction sites and commercial properties.
Building-Mounted Advertising
Can be cut into confirmed modules for promotional panels fixed to suitable secondary framing on exterior walls.
Outdoor Event Branding
Works for reusable branded panels and sponsor boards where an exterior PVDF surface and rigid sheet format are required.
Product Questions
Frequently Asked Questions
What makes this ACP suitable for outdoor advertising?
The product combines a 4mm composite section with a PVDF-coated exposed face selected for exterior colour stability and weather exposure.
Can advertising graphics be applied to the PVDF face?
Yes, when the ink, film or adhesive system has been checked for compatibility with the selected PVDF coating and surface preparation.
Which aluminium skin thickness should be ordered?
The available 0.20–0.40mm range should be selected around the panel size, support spacing, fixing method and fabrication requirements of the advertising board.
Can Alcadex cut panels for an existing billboard frame?
Yes. Cutting, sizing and drilling can be completed from approved dimensions and hole layouts before the panels are packed for shipment.
Are custom colours available for campaign boards?
Standard and approved project colours can be reviewed against coating feasibility, order quantity and physical sample approval.
Request a Quote for 4mm Outdoor Advertising ACP
Send the required panel dimensions, quantity, aluminium skin thickness, coating, colour or graphic process, and any processing drawings. Alcadex will review the confirmed build and prepare a manufacturing quotation for 4mm Outdoor Advertising ACP.
